| Article ID | Journal | Published Year | Pages | File Type |
|---|---|---|---|---|
| 1640371 | Transactions of Nonferrous Metals Society of China | 2007 | 6 Pages |
The melting point, spreading property, mechanical properties and microstructures of Sn-3.0Ag-2.8Cu solder alloys added with micro-variable-Ce were studied by means of optical microscopy, scanning electron microscopy(SEM) and energy dispersive X-ray(EDX). The results indicate that the melting point of Sn-3.0Ag-2.8Cu solder is enhanced by Ce addition; a small amount of Ce will remarkably prolong the creep-rupture life of Sn-3.0Ag-2.8Cu solder joint at room temperature, especially when the content of Ce is 0.1%, the creep-rupture life will be 9 times or more than that of the solder joint without Ce addition; the elongation of Sn-3.0Ag-2.8Cu solder is also obviously improved even up to 15.7%. In sum, the optimum content of Ce is within 0.05%–0.1%.
