Interfacial chemical and electronic structure of cobalt deposition on 2,7-dioctyl[1]benzothieno[3,2-b]benzothiophene (C8-BTBT)

Interfacial chemical and electronic structure of Co deposition on 2,7-dioctyl[1]benzothieno[3,2-b]benzothiophene(C8-BTBT) was investigated by ultraviolet photoemission spectroscopy (UPS) and X-ray photoemission spectroscopy (XPS). Chemical reaction of cobalt with C8-BTBT at the interface is confirmed by a new component of S 2s peak which is electron-rich compared to the original one of C8-BTBT molecules. Intensity evolution of the core level in XPS indicates that the adsorption of Co atoms is mainly at the surface without deeper diffusion into C8-BTBT layer. Initial deposition of Co atoms downward shifts the core levels of C8-BTBT by electron transfer from isolated Co atoms or clusters to the C8-BTBT. Further deposition of Co upward shifts the core levels of C8-BTBT because of the neutralization of the thicker metal Co film. Our investigation suggests an inert buffer layer inserted to protect organic layer from reaction or decomposition and to lower the carrier barriers for both the electron and hole to improve the performance of Co/C8-BTBT-based OFETs.
