Abstract
A Small Modular fast reactor cooled by Supercritical CO2 (SMoSC) is pre-conceptually designed through three-dimensional coupled neutronics/thermal-hydraulics analysis. The power rating of the SMoSC is designed to be 300Â MWth to meet the energy demand of small electrical grids. The excellent thermal properties of supercritical CO2 (S-CO2) are employed to obtain a high thermal efficiency of about 40% with an electric output of 120Â MWe. MOX fuel is utilized in the core design to improve fuel efficiency. The tube-in-duct (TID) assembly is applied to get lower coolant volume fraction and reduce the positive coolant void reactivity. According to the coupled neutronics/thermal-hydraulics calculations, the coolant void reactivity is kept negative throughout the whole core life. With a specific power density of 9.6Â kW/kg and an average discharge burnup of 70.1Â GWd/tHM, the SmoSC can be operated for 20 Effective Full Power Years (EFPYs) without refueling.
Related Topics
Physical Sciences and Engineering
Energy
Energy Engineering and Power Technology
Authors
Baolin Liu, Liangzhi Cao, Hongchun Wu, Xianbao Yuan, Kunpeng Wang,
