Article ID | Journal | Published Year | Pages | File Type |
---|---|---|---|---|
748994 | Solid-State Electronics | 2008 | 6 Pages |
Abstract
Due to the limited control of the short channel effects, the high junction leakage caused by band-to-band tunneling and the dramatically increased VT statistical fluctuations, the scaling of planar bulk MOSFETs becomes more and more problematic with every technology node. The ITRS roadmap predicts that from the 32 nm technology node on, planar bulk devices will not be able to meet the stringent leakage requirements anymore and that multi-gate devices will be required. In this paper, the suitability of FinFET-based multi-gate devices for the 32 nm technology and beyond will be discussed. Apart from the benefits, some technological challenges will be addressed.
Related Topics
Physical Sciences and Engineering
Engineering
Electrical and Electronic Engineering
Authors
N. Collaert, A. De Keersgieter, A. Dixit, I. Ferain, L.-S. Lai, D. Lenoble, A. Mercha, A. Nackaerts, B.J. Pawlak, R. Rooyackers, T. Schulz, K.T. San, N.J. Son, M.J.H. Van Dal, P. Verheyen, K. von Arnim, L. Witters, K. De Meyer, S. Biesemans, M. Jurczak,
