Abstract
Direct writing has recently emerged as a viable alternative to lithography for the fabrication of patterned metallic and semiconducting materials. State-of-the-art tools such as scanning electron beams and scanning probe microscopy have been implemented in direct-write strategies to produce arbitrary and complex patterns in fewer steps, with resolution capabilities as good or better than lithographic approaches. A common thread among many of the strategies is electron-driven chemistry. Here, we review this special class of direct-write techniques, highlighting advances, challenges, and future prospects.
Related Topics
Physical Sciences and Engineering
Chemistry
Chemistry (General)
Authors
Seung Whan Lee, R. Mohan Sankaran,
