Article ID | Journal | Published Year | Pages | File Type |
---|---|---|---|---|
9785789 | Optics Communications | 2005 | 7 Pages |
Abstract
The lensless digital in-line microscope is proposed as a simple tool for post-production inspection of metallic film patterns on silicon wafers. Transmission holographic imaging is achieved by using a superluminescent diode emitting in the near infrared coupled into a single-mode high numerical aperture optical fiber and an infrared vidicon camera. Images of 300Â nm thick vapor-deposited aluminum bolometers are presented.
Related Topics
Physical Sciences and Engineering
Materials Science
Electronic, Optical and Magnetic Materials
Authors
L. Repetto, R. Chittofrati, E. Piano, C. Pontiggia,
