| Article ID | Journal | Published Year | Pages | File Type |
|---|---|---|---|---|
| 814695 | Rare Metal Materials and Engineering | 2015 | 5 Pages |
Chrysanthemum-like ZnO nanowire clusters were prepared by hydrothermal process, then were transferred to Ti substrate by electrophoresis method, and uniform ZnO nano-film with certain thickness was formed. Finally ZnO field emission cathode sample was fabricated after vacuum heat treatment. The microstructure and the morphology of chrysanthemum-like ZnO nanowire clusters were characterized by X-ray diffraction (XRD) and scanning electron microscope (SEM), respectively. Field emission tests were conducted for cathode samples after heat treatment, results reveal that the low turn-on field is 2.0 V/μm for the chrysanthemum-like ZnO, and the threshold field is 5.5 V/μm. Moreover, the field emission current density is 200 μA/cm2 under the condition of electric field of 7.5 V/μm, and the field emission current density and its stability can be effectively improved by appropriate enlarging the thickness of the ZnO coating. The field emission mechanism was also explored.
