The rotor-blade driving torque and the meter factor of a tangential type turbine flowmeter are both deduced in theory. Based on computational fluid dynamics (CFD) and a turbulence model, a numerical investigation of the turbulent flow field of a tangential type turbine flowmeter is conducted to investigate the mechanism of the tangential type turbine flowmeter. The analysis method of the rotor-torque-balance in direction ZZ, which predicts the rotational speed θθ of a rotor precisely, is presented subsequently. The key information of the inner meter is obtained through analyzing the pressure flow field and velocity flow field. Comparing with the data of physical experiments, the maximum full-scale error of meter factor is just 7.51%. The results of the comparison show that the simulation model and the analysis method of a tangential type turbine flowmeter is feasible and effective.
Journal: Flow Measurement and Instrumentation - Volume 19, Issue 5, October 2008, Pages 233–239
