Design of FPGA-based Moore FMSs with counters

A method of hardware reduction is proposed for logic circuits of Moore FSMs implemented with FPGAs. The method is based on replacement of the state register by a state counter. The main di_erence form already known methods is that the counter increases its state during conditional and unconditional transitions. An example of application of proposed methods is given.
