From UML State Machine Diagram into FPGA Implementation
دانلود مقاله + سفارش ترجمه
دانلود مقاله ISI انگلیسی
رایگان برای ایرانیان
موضوعات مرتبط
مهندسی و علوم پایه
سایر رشته های مهندسی
مکانیک محاسباتی
پیش نمایش صفحه اول مقاله
چکیده انگلیسی
In the paper a method of using the Unified Modeling Language diagrams for specification of digital systems, especially logic controllers, is presented. The proposed method is based mainly on the UML state machine diagrams and uses Hierarchical Concurrent Finite State Machines (HCFSMs) as a temporary model. The paper shows a way to transform the UML diagrams to the form that is acceptable by reconfigurable FPGAs (Field Programmable Gate Arrays). The UML specification is used to generate an effective program in Hardware Description Languages (HDLs), especially Verilog.
