Designing a plano-convex aspheric lens for fiber optics collimator

A plano-convex aspheric lens is designed to collimate the emitted light of the fiber optics. In this paper even orders of general aspheres are used to describe the aspheric surfaces sag. To determine the aspheric coefficient, the even asphere polynomial are fitted on the computed sag data. The surface sag data is determined using genetic algorithm method. The surface sag was analyzed by the commercial optical software package ZEMAX. For typical fiber optics, the numerical aperture (NA) of 0.22 was assumed. With this specification, the expected output spot diagram of 20 mm and the maximum aperture of 25.4 mm have been obtained. A comparison between here presented lens and the similar type of conventional lens has been carried out; the proposed aspheric lens corrected the spherical aberration, which led to increase in the collimated distance.

► A plano-convex aspheric lens is designed to collimate the output of the fiber optics.
► Spherical aberration of the proposed lens was corrected so the collimated distance increases.
► Aspheric coefficients were obtained by fitting the even aspheric polynomials to sag data, using the genetic algorithm.
