Synthesis and characterizations of Ho2O3 modified SrBi2Nb2O9 ceramics

SrBi2-xHoxNb2O9 (0 ≤ x ≤ 0.5) ceramics were prepared through the conventional solid state route. The materials have been characterized by XRD, FTIR and SEM. All compounds were pure and well crystallized. In FTIR spectroscopy, the spectral patterns of the crystal structures of these polyphases are unique and smoothly different from each other. The grains were prone to become spherical with increasing x. Dielectric and electrical properties of these materials as a function of temperature at different frequencies have been carried out. The dielectric constant and dielectric loss were found to decrease with an increase of the holmium concentration at room temperature. Reaching up to x = 0.4 and x = 0.5, the diffusivity increases, leading to the occurrence of relaxor behavior. 20-30 at.% Ho doping on the Bi-site can fill up the oxygen vacancies and decrease the AC conductivity. However, at higher doping levels greater than 40% holmium oxide, the AC conductivity is found to increase.
