عنوان انگلیسی مقاله ISI
The common-base differential amplifier and applications revisited
ترجمه فارسی عنوان
تقویت کننده دیفرانسیل مشترک و برنامه های کاربردی مجددا بررسی شده است
دانلود مقاله + سفارش ترجمه
دانلود مقاله ISI انگلیسی
رایگان برای ایرانیان
موضوعات مرتبط
مهندسی و علوم پایه
مهندسی کامپیوتر
سخت افزارها و معماری
چکیده انگلیسی
In this paper, the common-base (or -gate) differential amplifier is revisited and presented. A variant of the same amplifier is also presented and both are analyzed using standard two-port network analysis. Their high frequency behavior, differences in biasing details and noise analysis are also compared and contrasted. New differential input-output filters are derived for the common-base (or -gate) differential amplifier as well as a new low impedance Norton amplifier. Simulations using Spectre in a 90Â nm UMC CMOS process of several of the filters as well as experiments conducted using discrete transistors confirm the theoretical results.
ناشر
Database: Elsevier - ScienceDirect (ساینس دایرکت)
Journal: Microelectronics Journal - Volume 63, May 2017, Pages 8-19
Journal: Microelectronics Journal - Volume 63, May 2017, Pages 8-19
نویسندگان
B.J. Maundy, Serdar Ozoguz, A.S. Elwakil, S.J.G. Gift,
