Ion beam-induced bending of silicon nanowires

Ion implantation is the standard technique for amorphizing and doping planar films and devices in the microelectronic mainstream. On the other hand, it could be successfully applied to dope axial nanostructures such as Si nanowires (NWs). We prepared high crystalline-quality Si NWs by electron beam evaporation, a well-diffused industrial technique, and we elucidated the effects of ion irradiation on these NWs. We demonstrated that ion implantation induces bending of the NW till a full alignment in the ion beam direction occurs. We find a minimum implanted fluence threshold for the deformation and we investigated the role of beam energy and of implanted fluence. These data allow us to establish a correlation between amorphization of the structure and bending of the NW.

Figure optionsDownload as PowerPoint slideResearch highlights
► Ion implantation induces amorphization and bending of the nanowires.
► Amorphized nanowires bend till a full alignment in the ion beam direction occurs.
► There is a minimum fluence threshold for the bending.
► The beam energy is correlated to the maximum size to observe bending of the NWs.
