Simultaneous assimilation of in situ soil moisture and streamflow in the SWAT model using the Extended Kalman Filter

The Extended Kalman Filter (EKF) is used to assimilate in situ surface soil moisture and streamflow observation at the outlet of an experimental watershed outlet into a semi-distributed SWAT (Soil and Water Assessment Tool) model. Watershed scale, instead of HRU scale soil moisture was used in state vector to reduce computational burden. Numerical experiments were designed to select the best state vector which consists of streamflow and soil moisture in all vertical soil layers. Compared to open-loop model and direct-insert method, the estimate of both soil moisture and streamflow has been improved by EKF assimilation. The combined assimilation of surface soil moisture and streamflow outperforms the assimilation with only surface soil moisture or streamflow especially in the estimate of full profile soil moisture. The NSC has been improved to 0.63 from −4.45 and the RMSE has been reduced to 12.34 mm from 47.44 mm in open-loop. Such improvement is also reflected in the short term forecast of soil moisture. The improvement of streamflow prediction is relatively moderate in both simulation and forecast mode compared to quality of the soil moisture prediction. The quantification of the model error, especially the error covariance between different state variables, was found to be critical to the estimate of the state variable corresponding to the error covariance.
